Solar Power Inverter Factory 5KW Off Grid Solar Inverter
5KW Off Grid Solar Kit
5KW Off Grid Solar Kit
5KW Off Grid Solar Kit

Solar Power Inverter Factory 5KW Off Grid Solar Inverter

5KW off grid solar inverter can supply power to air conditioner,fridge,TV,light,water pump etc.

Product Specification:
  • Output: 110V/120V/220V/230V/240VAC
Inquiry Now
  1. Product Details
  2. Download

Solar Power Inverter Factory 5KW Off Grid Solar InverterSolar Power Inverter Factory 5KW Off Grid Solar Inverter

Solar Power Inverter Factory 5KW Off Grid Solar Inverter



Solar Power Inverter Factory 5KW Off Grid Solar Inverter

off grid solar inverter product feature:

1) super wide input voltage: 160V---280VAC;

2) completely controlled by CPU, protect against output short-circuit/overload;

3) optional for charge build-in, charge current is 10A----30A.
4) different DC voltage: 12V, 24V, 36V, 48V, 96V, 110V,192V, 240V for optional.
5)
solar panel inverter kit operate with 120% of nominal load during 1 minute ;150% of nominal load during 10s.
6) it can drive inductive loads, such as lightings, TV sets, fans, refrigerators and air-conditioner.

7) When the AC comes, it will start the unit automatically; And when it overload, it will also close .the unit automatically, when you cancel the load, then it will return to work automatically.
8) ATM
solar panel inverter kit, RS232 software, SNMP card for optional.

9) 100% import IR American MOS and Mitsubishi IGBT.

10)double protection ,city power &battery working mode for optional.



Solar Power Inverter Factory 5KW Off Grid Solar Inverter

Model:

MT 5K

Rated power

5000W

Battery

Rated voltage

48VDC

Charge current

5-30A

Input

Voltage

85-138VAC/170-275VAC

Frequency

45-65HZ







Output

Voltage

110V-240VAC±5% (Inversion mode)

Frequency

50/60HZ±1% (inversion mode)

Output wave

Pure sine wave

Conversion time

<10ms (typical load)

Efficiency

>90% (85% resistive load)

Overload

110-120%/30S; >160%/300ms

Protection function

Battery overvoltage protection, battery undervoltage protection, overload protection, short circuit protection, overtemperature protection,etc

Ambient temperature for operation

0-40℃

Ambient temperature for storage

-15-+50℃

Operation/storage conditions

0-90% (no condensation)

External dimension:

265*225*610mm

Packing dimension:

290*340*680mm

Solar Power Inverter Factory 5KW Off Grid Solar Inverter

   Foshan Mars Solar Technology Co.,Ltd have more than 10 years factory experience for solar power products,solar street light products,off grid solar inverter products,solar appliance products.More than 3000 successfully case have installed in 130+ countries.Germany technology,China price,Global service. Sincerely welcome everyone join us and develop solar business.

Solar Power Inverter Factory 5KW Off Grid Solar Inverter

Inverter 5KW Off Grid Inverter 5KW Off Grid
Inverter 5KW Off Grid Inverter 5KW Off Grid

Inverter 5KW Off GridInverter 5KW Off Grid5KW Off Grid Solar Kit5KW Off Grid Solar Kit

Q:Are you factory?

A: Yes, our factory and sales department are located in Foshan and we would be pleased to welcome you in our factory at any time when you are in Foshan

Q:What is the warranty for this off grid solar inverter?

A:YES,All products are at least 2 years warranty.

Q:What is the shipping way?

A:DHL,UPS,TNT,EMS,FedEx, Ship by sea.

Q:What is the payment method?

A:We normally require a T/T advance payment. 30% deposit and 70% before shipping. Western Union/Money Gram can also be used.

Q:Can we design packaing?

A:YES.We can customer's own packing

Q:Can we customize product?

A:YES.OEM&ODM.

Q:Are there some optional function for your off grid solar inverter?

A:Yes,it have battery priority function, grid priority function, AC grid charger function, AVR function,RS232 interface telecommunication function. Solar energy inverter mostly use battery priority function, AC grid charger function. It can make full use of solar power.

Q:what is MARS off grid solar inverter after sales service?

A:during the warranty ,ship free PCB by DHL or FEDEX.
